3000w Motor With 17 Inch Motorcycle Wheel

17 inch motorcycle wheel with QS motor 3000 watt

QS Motor Specification

• Motor Type: BLDC Permanent Magnet Outer Rotor In-Wheel Hub Motor With Hall Sensor

• Brand: QS Motor, QSMOTOR

• Motor Design: Double axle without rim (not integrated), 36 spoke holes, OD 4.2mm

• Matching Rim size: 24inch, 26inch E-Bike Wheel, 17inch, 18inch, 19inch moped wheel.

• Magnet Height: 50mm, 16 pole pairs

• Stator: Aluminmum Core

• Rated Power: 3000W (14000W peak in few seconds)

• Rated Voltage: 72V as default (48V-96V, optional)

• Speed: 80KPH as default (24-120KPH, optional)

• kV: 6.3/7.3/8.1/8.3/9.0(as default)/10.6/11.4/13.3/14.3/16.3/17.7 etc.

• Max Torque: approx 182N.m

• Max Efficiency: 86-91%

• Continuous Battery Current: 52A (72V)

• Peak Battery Current: 104A (72V)

• Suggest Peak Phase Current: 196-245A (depend on the kV)

• Thermic Probe: KTY83/122 (as default, optional)

• Working Temperature: 70-120℃ , peak 150 ℃

• Brake type: Bike Disc brake, PCD6*44mm(as default)

• Drop-outs/Rear Fork Width for installation: 150-154mm

• 14mm english thread length for single/3 speed freewheel

• 10mm axle flats

• Dual Hall Set with waterproof connectors

• 10mm² Cross Section of Phase Wire (not include insulation layer)

• Hall Sensor Phasing angle: 120 degree

• Waterproof Grade: IP54

• Color: Black (as default), White/Luminous (extra $5.0)

• N.W./G.W.: 12.5kg/14.0kg Package Dimension: 34cm*34cm*33cm/piece
